Echinoteuthis famelica: Sucker Structure

Richard E. Young
  1. Tentacle suckers
  2. Click on an image to view larger version & data in a new window
    Click on an image to view larger version & data in a new window

    Figures. Oral view of a transverse strip of the tentacular club from near the base of the club. Hawaiian waters, ... mm ML.

    Click on an image to view larger version & data in a new window
    Click on an image to view larger version & data in a new window

    Figures. Left - Oral view of a club sucker. Right - Dorsal-oblique view of a different club sucker. Both suckers are from near the base of the club. Hawaiian waters, ... mm ML.

    Click on an image to view larger version & data in a new window
    Click on an image to view larger version & data in a new window

    Figure. Inner ring of a club sucker showing two small, rounded, distal teeth. Note the oblong shape of the aperature.

  3. Arm IV suckers
  4. Click on an image to view larger version & data in a new window
    Click on an image to view larger version & data in a new window

    Figure. Oral view of an arm IV sucker; sucker number 10 of the ventral series.

Comments

Scanning electron micrographs by R. Young
