Acanthopterygii Johnson and Patterson 1993

E. 0. Wiley and G. David Johnson
Click on an image to view larger version & data in a new window
Click on an image to view larger version & data in a new window
Red-tailed Wrasse
taxon links [up-->]Percomorpha [down<--]Acanthomorpha Interpreting the tree
close box

This tree diagram shows the relationships between several groups of organisms.

The root of the current tree connects the organisms featured in this tree to their containing group and the rest of the Tree of Life. The basal branching point in the tree represents the ancestor of the other groups in the tree. This ancestor diversified over time into several descendent subgroups, which are represented as internal nodes and terminal taxa to the right.

example of a tree diagram

You can click on the root to travel down the Tree of Life all the way to the root of all Life, and you can click on the names of descendent subgroups to travel up the Tree of Life all the way to individual species.

For more information on ToL tree formatting, please see Interpreting the Tree or Classification. To learn more about phylogenetic trees, please visit our Phylogenetic Biology pages.

close box
Containing group: Acanthomorpha


Acanthopterygii comprises three relatively small, sequential, worldwide marine clades, Stephanoberyciformes, Zeiformes, and Beryciformes as well as the largest and most diverse group of fishes, the Percomorpha. Stephanoberyciforms (90 species in nine families) include deepwater benthic and pelagic fishes commonly called pricklefishes and whalefishes. Johnson and Patterson (1993) separated this clade from the Beryciformes, but molecular data suggest that at least some members of the group might rejoin it (e.g., Wiley et al., 2000; Colgan et al., 2000; Chen et al., 2003; Miya et al., 2001, 2003, 2005). Zeiforms (45 species in five families) are mostly deep-bodied, deep-sea fishes that include the highly prized John Dory of the eastern Atlantic and Indo-Pacific. Most molecular studies (e.g., Wiley et al., 2000; Miya et al., 2001, 2003, 2005; Chen et al., 2003) suggest that cods and dories might be related. Beryciforms (145 species in seven families) occur from shallow depths, where they tend to be nocturnal (e.g., the well known reef dwelling squirrelfishes), to the deep sea. They include the bioluminescent pinecone and flashlight fishes as well as the commercially important and overexploited food fish, the orange roughy. The Percomorpha are the crown group of the spiny-rayed fishes, comprising more than 14,000 species in 244 families.



  1. Pelvic fin spine present. A variable character lost in some members of each major group (see discussion in Johnson and Patterson, 1993).
  2. Free pelvic radials reduced in size and/or number (Johnson and Patterson, 1993).
  3. An anteromedial process (styliform process) present on the pelvic bone (Stiassny and Moore, 1992). A variable character absent in non-melamphaid stephanoberyciforms, zeiforms, some atherinomorphs, and all gasterosteiforms (Johnson and Patterson, 1993).

Discussion of Phylogenetic Relationships

As originally conceived by Greenwood et al. (1966), Acanthopterygii included Percomorpha (tunas, basses, etc.) but excluded Atherinomorpha (killifishes, silversides, etc.). Rosen and Patterson (1969) united these two groups and ranked them co-equal with Paracanthopterygii. Thus, Acanthomorpha contained two major groups, Paracanthopterygii and Acanthopterygii.

The period between 1969 and the present has seen changes in the composition of both groups. Rosen (1985) and Stiassny (1986) removed the Polymixiiformes (beardfishes) from Acanthopterygii to the base below Paracanthopterygii, and Stiassny and Moore (1992) suggested that the Lampridiformes (oarfishes and allies) might also be basal. In their new proposal of acanthomorph relationships Johnson and Patterson (1993) corroborated both of these hypotheses and thus redefined the Acanthopterygii, placing Polymixiiformes and Lampridiformes as sequential sister groups to the remaining acanthomorphs (Paracanthopterygii,Acanthopterygii, their Holacanthopterygii).

The basal placement of polymixiiforms and lampridiforms has subsequently been supported in DNA studies (e.g., Wiley et al., 2000; Miya et al., 2001, 2003, 2005). However, there has been a growing recognition that the Paracanthopterygii is polyphyletic and the Acanthopterygii paraphyletic. Johnson and Patterson (1993) used only Percopsiformes to represent Paracanthopterygii, assuming the monophyly of the group following Patterson and Rosen (1989). Gill (1997) suggested that the morphological evidence for monophyly of Paracanthopterygii is weak. DNA studies (e.g., Le et al., 1993; Wiley et al. 2000; Miya et al., 2001, 2003, 2005) suggest that Paracanthopterygii is polyphyletic, with Gadiformes and Percopsiformes being basal at the level previously shown for Paracanthopterygii, and Lophiiformes, Batrachoidiformes, and Ophidiiformes embedded within the Acanthopterygii of Johnson and Patterson (1993).


Colgan, D. J. C., C. Zhang, and J. R. Paxton. 2000. Phylogenetic investigations of the Stephanoberyciformes and beryciformes, particularly whalefishes (Euteleostei: Cetomimidae), based on partial 12S rDAN and 16s rDNA sequences. Mol. Phylogenet. Evo. 17(1):15-25.

Chen, W.-J., C., Bonillo, and G. Lecointre. 2003. Repeatability of clades as a criterion of reliability: a case study for molecular phylogeny of Acanthomorpha (Teleostei) with larger number of taxa. Mol. Phylo. Evol. 26(2):262-288.

Gill, A. C. 1996. Comments on an intercalar path for the glossopharyngeal (Cranial IX) nerve as a synapomorphy of the Paracanthopterygii and on the phylogenetic position of the Gobiesocidae (Teleostei: Acanthomorpha) Copeia 1996(4), 1022-1029.

Greenwood, P. H., D. E Rosen, S. H. Weitzman and G. S. Myers. 1966. Phyletic studies of teleostean fishes, with a provisional classification of living forms. Bull. Am. Mus. Nat. Hist. 131:339-456.

Johnson, G. D. and C. Patterson. (1993) Percomorph phylogeny: A survey of acanthomorph characters and a new proposal. Bull. Mar. Sci. 52, 554-626.

Le, H. L. V., G. Lecointre, and R. Perasso. 1993. A 28S rRNA-based phylogeny of the gnathostomes: first steps in the analysis of conflict and congruence with morphologically based cladograms. Mol. Phylogenet. Evol. 2(1):31-51.

Miya, M. A, A. Kawaguchi, and M. Nishida. 2001. Mitogenomic exploration of higher teleostean phylogenies: a case study of moderate-scale evolutionary genomics with 38 newly determined complete mitochondrial DNA sequences. Mol. Biol. Evol. 18(11)1993-2009.

Miya, M., H. Takeshima, H. Endo, N. B. Ishiguro, J. G. Inous, T. Mukai, T. P. Satoh, M. Yamagucki, A. Kawaguchi, K. Mabuchi, S. M. Shirai, and M. Nishida. 2003. Major patterns of higher teleost phylogenies: a new perspective based on 100 complete mitochondrial DNA sequences. Mol. Phylo. Evol. 26:121-138.

Miya, M., Satoh, T.P., and Nishida. 2005. The phylogenetic position of toadfishes (Order Batrachoidiformes)in the higher ray-finned fishes as inferred from partitioned Bayesian analysis of 102 whole mitochondrial sequences. Biol. Jour. Linn. Soc. 85:289-306

Patterson, C., and D. E. Rosen. 1989. The Paracanthopterygii revisited: Order and disorder. Nat. Hist. Mus. Los Angeles Co. Sci. Ser. 32:5-36.

Rosen, D. E. 1985. An essay on euteleostean classification. Am. Mus. Novit. 2827:1-57.

Rosen, D. E. and C. Patterson. 1969. The structure and relationships of the paracanthopterygian fishes. Bull. Am. Mus. Nat. Hist. 141(3):361-474.

Stiassny, M. L. J. (1986) The limits and relationships of the acanthomorph fishes. J. Zool. London (B) 1:411-460.

Stiassny, M. L. J., and J. A. Moore. (1992) A review of the pelvic girdle of acanthomorph fishes, with comments on hypotheses of acanthomorph interrelationships. Zool J. Linn.Soc. London 104, 209-242.

Wiley, E. O., G. D. Johnson, and W. W. Dimmick. 2000. The interrelationships of acanthomorph fishes: a total evidence approach using morphological and molecular data. Biochem. Syst. Evol. 28(2000):319-350.

Title Illustrations
Click on an image to view larger version & data in a new window
Click on an image to view larger version & data in a new window
Red-tailed Wrasse
Scientific Name Anampses chrysocephalus
Comments Red-tailed Wrasse
Creator Jerry Ludwig
Specimen Condition Live Specimen
Source Collection U.S. Fish and Wildlife Service Online Digital Media Library
Scientific Name Priacanthus cruentatus
Location Bonaire's Calabas Reef, Netherland Antilles
Specimen Condition Live Specimen
Source My... What Big Eyes You Have!
Source Collection Flickr
Image Use creative commons This media file is licensed under the Creative Commons Attribution License - Version 2.0.
Copyright © 2006 LASZLO ILYES
About This Page

E. 0. Wiley
University of Kansas, Lawrence, Kansas, USA

Smithsonian Institution, Washington, D. C., USA

Correspondence regarding this page should be directed to E. 0. Wiley at and G. David Johnson at

All Rights Reserved.

Citing this page:

Wiley, E. 0. and G. David Johnson. 2007. Acanthopterygii Johnson and Patterson 1993. Version 09 January 2007 (under construction). http://tolweb.org/Acanthopterygii/15094/2007.01.09 in The Tree of Life Web Project, http://tolweb.org/
