'radial centric diatoms'

David G. Mann
Click on an image to view larger version & data in a new window
Click on an image to view larger version & data in a new window
Living CoscinodiscusActinocyclus thecaRhizosolenia cell

Some molecular phylogenies indicate that the radial centric diatoms are paraphyletic with respect to a monophyletic group containing the polar centric diatoms and pennate diatoms. There is little support for monophyly or paraphyly. The radial centrics are regarded as a class or (Coscinodiscophyceae) or subdivision/subphylum (Coscinodiscophytina) by some authors

taxon links [up-->]coscinodiscids [up-->]rhizosolenids [up-->]melosirids [up-->]Corethron Monophyly UncertainPhylogenetic position of group is uncertainPhylogenetic position of group is uncertainPhylogenetic position of group is uncertainPhylogenetic position of group is uncertainPhylogenetic position of group is uncertainPhylogenetic position of group is uncertain[down<--]Diatoms Interpreting the tree
close box

This tree diagram shows the relationships between several groups of organisms.

The root of the current tree connects the organisms featured in this tree to their containing group and the rest of the Tree of Life. The basal branching point in the tree represents the ancestor of the other groups in the tree. This ancestor diversified over time into several descendent subgroups, which are represented as internal nodes and terminal taxa to the right.

example of a tree diagram

You can click on the root to travel down the Tree of Life all the way to the root of all Life, and you can click on the names of descendent subgroups to travel up the Tree of Life all the way to individual species.

For more information on ToL tree formatting, please see Interpreting the Tree or Classification. To learn more about phylogenetic trees, please visit our Phylogenetic Biology pages.

close box
Containing group: Diatoms

Introduction

The radial centric diatoms have circular valves and lack obvious signs of bi- or multipolarity in the arrangement of special pores or processes (there are very rare exceptions). They are probably a paraphyletic group of lineages that split from each other before the evolution of more complex (non-circular) valve shapes in the ancestors of the 'polar centric diatoms'. Current molecular data do not give a clear picture of the relationship between the radial centrics and the polar centrics, nor of the relationships among major groups within the radial centrics.

The definition of radial centrics is in fact wholly negative. They are those lineages of diatoms that (1) have circular valves because they lack the special siliceous bands that force the auxospore to expand anisometrically, (2) lack fultoportulae and so are not circular-valved members of the Thalassiosirales, and (3) do not possess the synapomorphies of the few other groups of diatoms that have circular valves.

Even if the radial centrics do prove to be monophyletic (e.g. as in the diagram of Sims et al. 2006, fig. 2), it is highly unlikely that any morphological features will be consistently useful for diagnosis.

If they are paraphyletic, we can hope that a classification will eventually be developed that truly reflects evolutionary relationships. In the meantime, the name 'radial centrics' is simply a shorter and more descriptive quick-reference than 'lineages that probably diverged from each other earlier than all except one of them from the polar centrics (including pennates), that lack a sternum, that have an annulus but lack fultoportulae and discrete areas of porelli, and that lack elongate or multipolar shapes through having a simple auxospore wall'.

The radial centric diatoms are mostly planktonic and marine, but there are interesting exceptions. Ellerbeckia arenaria is often semi-terrestrial, occurring on damp shady rocks. Some Melosira species occur in freshwater periphyton, and Aulacoseira is an important component of freshwater phytoplankton, usually in well-mixed water columns.

Characteristics

Discussion of Phylogenetic Relationships

The relationships between the major groups of radial centrics are unclear and many groups of species and genera have not been studied in detail, nor included in molecular phylogenies. Ellerbeckia sol (also called 'Paralia sol') sometimes appears as sister to all other diatoms (e.g. Medlin & Kaczmarska 2004, Alverson et al. 2006), and Leptocylindrus also sometimes splits off very early (e.g. Alverson et al. 2006, Sorhannus 2007).

The rich Lower Cretaceous flora described by Gersonde & Harwood (1990) contains several genera that possess the characteristics of radial centrics, i.e. with circular valves but without features that might place them among the polar centric lineages (discussed by Medlin & Kaczmarska 2004, Sims et al. 2006). Some of these show no obvious links to any of the extant groups of radial centrics.

Medlin & Kaczmarska (2004) refer to the radial centric diatoms as the subdivision Coscinodiscophytina.

Other Names for 'radial centric diatoms'

References

Alverson, A.J., Cannone, J.J., Gutell, R.R. & Theriot, E.C. (2006). The evolution of elongate shape in diatoms. Journal of Phycology 42: 655-668.

Gersonde, R. & Harwood, D.M. (1990). Lower Cretaceous diatoms from ODP Leg 113 site 693 (Weddell Sea) Part 1: vegetative cells. Proceedings of the Ocean Drilling Program, Scientific Results 113: 365–402.

Medlin, L.K. & Kaczmarska, I. (2004). Evolution of the diatoms: V. Morphological and cytological support for the major clades and a taxonomic revision. Phycologia 43: 245–270.

Round, F.E., Crawford, R.M. & Mann, D.G. (1990). The diatoms. Biology and morphology of the genera. Cambridge University Press, Cambridge. 747 pp.

Sims, P.A., Mann, D.G. & Medlin, L.K. (2006). Evolution of the diatoms: insights from fossil, biological and molecular data. Phycologia 45: 361-402.

Sorhannus, U. (2007). A nuclear-encoded small-subunit ribosomal RNA timescale for diatom evolution. Marine Micropaleontology 65: 1-12.

Title Illustrations
Click on an image to view larger version & data in a new window
Click on an image to view larger version & data in a new window
Living Coscinodiscus
Scientific Name Coscinodiscus
Identified By David G. Mann
Life Cycle Stage Vegetative phase
Image Use creative commons This media file is licensed under the Creative Commons Attribution-NonCommercial License - Version 3.0.
Copyright © 2008 David G. Mann
Actinocyclus theca
Scientific Name Actinocyclus
Specimen Condition Dead Specimen
Identified By David G. Mann
Life Cycle Stage Vegetative phase
Body Part theca
View external, SEM
Copyright © 2008 David G. Mann
Rhizosolenia cell
Scientific Name Rhizosolenia
Reference G. Karsten (1905). Das Phytoplankton des Antarktischen Meeres nach dem Material der deutschen Tiefsee-Expedition 1898-1899. Wissenschaftliche Ergebnisse der Deutchen Tiefsee-Expedition auf dem Dampfer "Valdivia" 1898-1899, 2 (2): 1-136.
Creator George Karsten
Acknowledgements scanned from G. Karsten (1905), plate 10, fig. 5d.
Specimen Condition Live Specimen
Life Cycle Stage Vegetative phase
View girdle view
Image Use creative commons This media file is licensed under the Creative Commons Attribution-NonCommercial License - Version 3.0.
Copyright © 2008 David G. Mann
